Sinusoidal Ramp
Traffic Calming
Sinusoidal Ramp
Our new Sinusoidal Ramp is designed to allow traffic to traverse more comfortably than a traditional speed cushion, whilst being severe enough to deter vehicles from speeding. This also offers ideal solutions for active travel, emergency vehicles cargo bikes and other road users.
Key Facts
- Versatile
Alternative speed ramp for Active Travel, providing a smoother transition - Easy Installation
Surface mounted, no excavation, preformed to provide a consistent sinusoid profile - Design Feature
Offers a shallower initial rise compared to traditional speed cushions and humps - Modular System
Standard length 3.1 m x 75 mm high, with the option of 4.1 m l. - Environment
Recycled product made in the UK
Sinusoidal Ramp
Technical Information
| Front Module | 400 mm wide |
| 900 mm long | |
| 75 mm high | |
| Middle Module | 400 mm wide |
| 650 mm long | |
| 75 mm high | |
| Intermediate Module | 400 mm wide |
| 900 mm long | |
| 75 mm high |
Available as a Kerb to Kerb solution which is installed across the road (Tapered sides option to follow).
Available in two sizes: 3.1 metres long x road width 4.1 metres long x road width
The Sinusoidal Ramp is a registered design
of Rediweld Traffic Products Limited.
